33
Using BIOS
The chipset menu items allow you to change the settings for the North chipset,
South chipset and other system.
Chipset Menu
North Bridge
Scroll to this item and press <Enter> and view the following screen.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
North Bridge Parameters
North Bridge
South Bridge
Main Advanced Chipset Frequency/Voltage Control Boot Security Save & Exit
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
IGD Share Memory Size
North Chipset Configuration
IGD Memory [Auto]
Azalia Internal HDMI codec [Enabled]
Main Advanced Chipset Frequency/Voltage Control Boot Security Save & Exit
IGD Memory (Auto)
This item shows the information of the IGD(Internal Graphics device) memory.
Azalia Internal HDMI codec (Enabled)
This item allows you to enable or disable the Azalia Internal HDMI codec.
Press <Esc> to return to the chipset menu page.
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
