ECS Elitegroup HDC-I2/E-450 [8/64] Introducing the motherboard
![ECS Elitegroup HDC-I2/E-450 [8/64] Introducing the motherboard](/views2/1212409/page8/bg8.png)
4
Introducing the Motherboard
• AMD Hudson D1 chipset
• Onboard AMD FT1 CPU(AMD dual core E-350 APU/AMD
single core E-240 APU/AMD dual core C-50 APU/AMD single
core C-30 APU)*
• Single-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports 1066/800 DDR3 SDRAM
• Supported by AMD Hudson D1 chipset
• 2 x Serial ATA 3.0 Gb/s devices
• VIA VT1705
• AR8151 GigaLAN (optional 10/100 LAN AR8152)
• 1 x DVI port (optional HDMI port)
• 1 x VGA port
• 8 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in, line out)
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 16Mb SPI Flash ROM
• Supports ACPI & DMI
• Supports Plug and Play, STR(S3)/STD(S4), Hardware monitor,
• Audio, LAN, can be disabled in BIOS
• Supports Dual Display (optional)
System BIOS
Form Factor
• Mini-ITX 170mm x 170mm
CPU
Specifications
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers
• 1 x Front panel audio header
• 1 x Speaker header
• 1 x LVDS header (optional)
• 1 x CASE open header
• 1 x 10-pin Front panel switch/LED header
• 2 x SATA 3Gb/s connectors
• 1 x PCI slot
*The onboard CPU is optional, please take the actual motherboard as the
standard.
