KBN-I USER MANUAL
29
Chapter 3
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as CPU fan speed, CPU & DIMM voltage...etc.
Press <Esc> to return to the Advanced Menu page.
Smart Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quiet mode, the
fan speed will be auto minimized for quiet environment. If you choose Silent mode,
the fan speed will be auto restricted to make system more quietly. If you choose
Manual mode, the fan speed will be adjusted depending on users’ parameters.
Press <Esc> to return to the PC Health Status page.
• CPU Tcl
• CPU Fan Speed
• System Fan Speed
• CPU Voltage
• DIMM Voltage
• +12V
