5
KBN-I USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. SYS_FAN System cooling fan connector
2. CPU_FAN CPU cooling fan connector
3. DIMM_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. F_PANEL Front panel switch/LED header
6. BZ Buzzer
7. SATA3_1~2 Serial ATA 6.0 Gb/s connectors
8. PCIEX16 PCI Express slot for graphics interface
9. F_AUDIO Front panel audio header
10. SPDIFO SPDIF out header
11. F_USB Front panel USB 2.0 header
12. TPM Trusted Platform Module header
13. MPCIE1/2 Mini PCI-Ex1 slots
14. CLR_CMOS Clear CMOS jumper
15. COM2 Onboard serial port header
16. CASE Case open header
17. LPT Onboard parallel port header
* The MB images are for reference only, please take the actual motherboard as
standard, and the other CPUs’ Cooler/Heat Sink may be different.
