Chapter 1
2
KBN-I USER MANUAL
CPU
Specifications
• AMD Kabini (SoC)Chipset
• Single-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 32 GB
• Supports DDR3 1600/1333 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen2 slot (runs at X4 mode)
• 2 x Mini PCI Express x1 slots
Expansion
Slots
Storage
• 1 x PS/2 Combo & USB connectors
• 1 x D-Sub port (VGA)
• 1 x COM1 port
• 1 x HDMI port
• 4 x USB 2.0 ports & 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, Line out, Mic_in Rear)
Rear Panel I/O
LAN
• AMD Socket FT3 processors
• Supports FT3 CPU (KBN-I/5200, KBN-I/2100, KBN-I/5000, KBN-
I/3000, KBN-I/2500)
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 3-pin CPU_FAN header
• 1 x 4-pin SYS_FAN header
• 1 x USB 2.0 header supports additional two USB 2.0 ports
• 2 x SATA 6Gb/s connectors
• 2 x COM (1 header & 1 connector)
• 1 x Case open header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Parallel port header(LPT)
• 1 x CLR_CMOS header
• 1 x SPDIF out header
• 1 x TPM header
• 1 x LPT header
• 1 x BZ header
Internal I/O
Connectors &
Headers
Audio
• Supported by AMD KABINI
• 2 x Serial ATA 6.0 Gb/s Host Controllers
• VT1705CF 6-ch High Definition audio CODEC
• Compliant with HD audio specification
• Realtek RTL8111E Gigabit LAN
