KBN-I USER MANUAL

Chapter 1

Introducing the Motherboard

Introduction

Your motherboard package ships with the following items:

Package Contents

KBN-I Motherboard

Quick Installation Guide

User Manual

DVD

I/O Shield

2 SATA Cables



The package contents above are for reference only, please take the actual

package items as standard.

Thank you for choosing the KBN-I motherboard of high performance, enhanced

function. This motherboard has onboard FT3 CPU (KBN-I/5200, KBN-I/2100, KBN-I/

5000, KBN-I/3000, KBN-I/2500) with an ITX form factor of 170 x 170 mm.

The motherboard incorporates the

AMD Kabini (SoC) chipset. It supports one

PCIEX16

slot

, intended for Graphics Interface. And two Mini PCIE*

slots are also

supported, which are for extending usage

. This motherboard supports up to 32 GB

of system memory with single channel DDR3 1600/1333

MHz.

It integrates USB 2.0 and USB 3.0 interface, supporting up to six USB 2.0 ports (four

USB 2.0 ports at rear panel and one USB 2.0 header supports additional two USB

2.0 ports) and two USB 3.0 ports at the rear panel.

The motherboard is equipped with advanced full set of I/O ports in the rear panel,

including PS/2 Combo & USB connectors, one HDMI port, one VGA port, one COM1

port, four USB 2.0 ports, two USB 3.0 ports, one LAN port, and audio jacks for

microphone, line-in and line-out.

*1 PCIEX16 slot runs at X4 mode.

*2 The Mini PCIE slots do not support mSATA.
