Chapter 2

H61H2-M8 USER MANUAL

2-4-5. Connecting Optional Devices

Refer to the following for information on connecting the motherboard’s optional

devices:

No. Components No. Components

1 SATA1~4 5 F_AUDIO

2F_USB1~2 6 LDC

3LPT7USB3F

4 COM —— ——

SATA1~4 connectors are used to support the Serial ATA 3Gb/s device. Simpler disk

drive cabling and easier PC assembly. It eliminates limitations of the current Paral-

lel ATA interface. But maintains register compatibility and software compatibility

with Parallel ATA.

1. SATA1~4: Serial ATA connectors
