5
H61H2-M8 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
2. ATX12V 4-pin +12V power connector
3. CPU_FAN 4-pin CPU cooling fan connector
4. DDR3_1~2 240-pin DDR3 Module slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SYS_FAN 4-pin system cooling fan connector
7. SPK Speaker header
8. SATA1~4 Serial ATA 3.0 Gb/s connectors
9. LDC Debug card header
10. F_PANEL Front panel switch/LED header
11. CLR_CMOS Clear CMOS jumper
12. F_USB1~2 Front panel USB 2.0 headers
13. LPT Printer Header
14. COM Onboard serial port header
15. F_AUDIO Front panel audio header
16. PCIE PCI Express x1 slot
17. PCIEX16 PCI Express slot for graphics interface
18. USB3F Front panel USB 3.0 header (Optional)
1. CPU Socket
LGA1155 socket for latest Intel®Core
TM
Family/
Pentium®Celeron® Processors
