H61H2-M8 USER MANUAL

Chapter 3

Enhanced Intel SpeedStep Technology (Enabled)

This item allows users to enable or disable the EIST(Enhanced Intel SpeedStep Tech-

nology).

Graphics Voltage(1/256) (0)

This item allows you to adjust the internal GFX voltage.

Graphics Core Ratio Limit (21)

This item allows you to control the internal GFX Turbo ratio
