Chapter 2

H61H2-M8 USER MANUAL

After you have installed the motherboard into a case, you can begin connecting the

motherboard components. Refer to the following:

2-4-7. Connecting Case Components

No. Components No. Components

1 ATX12V 4 SYS_FAN

2 CPU_FAN 5 SPK

3 ATX_POWER 6 F_PANEL
