H61H2-M8 USER MANUAL

Chapter 1

• 1 x 24-pin ATX Power Supply connector

• 1 x 4-pin 12V Power connector

• 1 x 4-pin CPU_FAN connector

• 1 x 4-pin SYS_FAN connector

Internal I/O

Connectors &

Headers

System BIOS

Form Factor

• Micro ATX Size, 225mm x 170mm

AP Support

• Supports eBLU/eDLU/eSF (Warning: Microsoft .NET Frame

work 3.5 is required)

• 4 x SATA 3Gb/s connectors

• 1 x Onboard Serial port header (COM)

• 1 x Front Panel switch/LED header

• 1 x Front Panel audio header

• 1 x Clear CMOS jumper

• 1 x Speaker header

• 1 x Debug card header (LDC)

• AMI BIOS with 32Mb SPI Flash ROM

- Supports Plug and Play

- Supports ACPI & DMI

- Supports STR (S3) /STD (S4)

- Supports Hardware monitor

- Audio, LAN, can be disabled in BIOS

- F7 hot key for boot up devices option

- Supports PgUp clear CMOS Hotkey (Has PS2 KB Model only)

- Supports Dual Display

- Supports GUI UEFI BIOS

- Supports Multi-Language

- Supports AC’97/HD Audio auto detect (default)

• 2 x USB 2.0 headers support additional four USB 2.0 ports

• 1 x USB3F header supports additional two USB 3.0 ports

* Please take the actual motherboard as standard or contact

the manufacturer to check whether this board supports USB

3.0 function or not, and USB 3.0 location will be different.
