GBC WireBind W18 [4/38] Location of controls
![GBC WireBind W18 [4/38] Location of controls](/views2/1218779/page4/bg4.png)
Location of controls
1
Document separator
2
Clippings tray (located at side of machine)
3
Wire closing handle
4
Paper centering dial
5
Wire binding channel
6
Quick start guide (W20, W25E only)
7
Electric punch button (W25E only)
8
Wire selector (W20, W25E only)
9
On/Off switch (W25E only)
J
Punching slot
K
Punching handle (W18, W20 only)
4
Special notice
Thank you for choosing a GBC Binding Machine. We aim to produce
quality binding machines at an affordable price, with many advanced
features to enable you to create excellent results every time. Before
using your machine for the first time, please take a few minutes to read
through this guide and retain these instructions for future reference.
Safety instructions
YOUR SAFETY AS WELL AS THE SAFETY OF OTHERS IS IMPORTANT
TO ACCO BRANDS EUROPE. IN THIS INSTRUCTION MANUAL AND ON
THE PRODUCT ARE IMPORTANT SAFETY MESSAGES. READ THESE
MESSAGES CAREFULLY.
• In order to avoid overloading your machine, please refer to the
maximum punch guide located on the front of your machine before
punching.
• When punching PVC/PP covers, we recommend the cover be punched
with some paper either side.
• DO NOT punch metallic objects such as staples or paper clips.
• Please empty the waste tray regularly.
• Ensure that the machine is operated on a at stable surface.
• Never lift the machine by the punching handle. Always use the hand
grips located on the side of the machine.
• To avoid risk of injury DO NOT put your ngers into the wire binding
channel.
•
The binder is not to be exposed to temperature / humidity conditions
that would cause condensation. Maximum ambient temperature ~40ºC.
m
Setting up
• Your machine is ready to use when removed from the box. Retain the
packaging in case you need to return the machine for repair.
• The punching mechanism is coated with a protective lm of lubricant,
which will mark your paper. Clear this by punching scrap sheets of
paper until clean prior to binding.
W25E is approved to EN60950 and CE Standards.
Technical data subject to change without notication.
Safety tips - W25E
• DO NOT obstruct air inlets and outlets.
• DO NOT use the binder if the power cord (mains cable) is damaged.
• DO NOT place the power cord where it may be tripped over or pulled.
Ensure it does not come into contact with hot surfaces such as pipes
or radiators. Make sure the cable is not squashed or pinched.
• DO NOT use an extension cable unless it is absolutely necessary and
then only use one of a suitable current rating (10A or greater).
• DO NOT leave the binder connected to the electricity supply when
not in use.
• DO NOT immerse the binder in water or other liquids. Doing so will
result in ELECTRIC SHOCK.
• DO NOT attempt to disassemble the binder. Always consult a qualied
person.
• The noise emitted by the machine does not exceed 70 dB.
m
Setting up - W25E
• Connect the binder to the electricity supply with the power cord
supplied.
• Switch ON using the ON/OFF switch located at the rear of the binder
by the power inlet socket.
• Wait while the binder goes through an automatic check procedure,
both LED’s light up.
• When complete the green LED will remain ON.
• For foot pedal operation of the punching cycle, connect the foot pedal
cable to the socket at the front of the machine.
• The binder is ready for operation.
WARNING: This appliance MUST be earthed.
If in doubt consult a qualified electrician.
m
Maintenance options
• If you would like to extend your warranty coverage beyond the stated
manufacturers period, please consult your local ACCO Brands Europe
reseller for options.
Specifications
Operation mode
Max. binding size
Hole pitch
Number of punch slots
Margin depth
Punching paper (80gsm)
Punching PVC plastic
foils (0.2mm)
Max. wire diameter
Binding capacity
Net weight
Dimensions WxDxH
Voltage
GBC W20 Wire Binder
manual
A4
International pitch 3.1”
(8.46mm)
34
fixed
max. 20
max. 2
14mm
125 sheets
13.14kg
495x450x200mm
n/a
GBC W25E Wire Binder
electric
A4
International pitch 3.1”
(8.46mm)
34
fixed
max. 25
max. 2
14mm
125 sheets
18.1kg
495x450x170mm
230V 50Hz AC
GBC W18 Wire Binder
manual
A4
International pitch 3.1”
(8.46mm)
34
fixed
max. 15
max. 2
14mm
125 sheets
11kg
470x450x200mm
n/a
