Деталировка двигателя B_S 12J802 Страница: 11

Тарпан ТМЗ-МК-03 [11/16] 11 assemblies include all parts shown in frames 10 31 2007 11

12J800

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0991−11 Assemblies include all parts shown in frames. 10/31/2007

46 691449 Camshaft

(Used After Code Date

96060200).

−−−−−−− Note −−−−−

492830 Camshaft

(Used Before Code

Date 96060300).

46A 691460 Camshaft

(Clockwise)

(Used After Code Date

96060200).

Used on Type No(s).

0818, 1322, 1331,

1338, 1918, 1969,

2850, 2950.

−−−−−−− Note −−−−−

493740 Camshaft

(Clockwise)

(Used Before Code

Date 96060300).

Used on Type No(s).

2850.

691459 Camshaft

(Counterclockwise)

(Used After Code Date

96060200).

Used on Type No(s).

0826, 1325, 1326,

1331, 1333, 1338,

1340, 1369, 1550,

1936, 1969, 2650,

2851, 2951, 2952,

2981, 3125, 3126,

3129.

50 497465 Manifold−Intake

51 K272199S Gasket−Intake

54 691650 Screw

(Intake Manifold)

55 691421 Housing−Rewind

Starter

55A 492831 Housing−Rewind

Starter

57 491889 Spring−Rewind Starter

58 280399S Rope−Starter

(Cut To Required-

Length)

59A 396892 Insert−Grip

60 281434S Grip−Starter Rope

(1 Piece)

60B 393152 Grip−Starter Rope

(2 Piece)

65 690837 Screw

(Rewind Starter)

−−−−−−− Note −−−−−

690759 Screw

(Rewind Starter)

(Use With Spring/Dog

Kit Starter)

73 691221 Screen−Rotating

78 691108 Screw

(Flywheel Guard)

81 691740 Lock−Muffler Screw

83 690522 Shaft−Auxiliary Drive

−−−−−−− Note −−−−−

691778 Shaft−Auxiliary

Drive

Used on Type No(s).

0818, 0826, 1338,

1340, 1918, 1969.

690527 Shaft−Auxiliary

Drive

Used on Type No(s).

1326, 1550, 2650,

2952, 3125, 3126,

3129.

94 D493765 Kit−Idle Mixture

95 691636 Screw

(Throttle Valve)

97 493267 Shaft−Throttle

(Metal)

−−−−−−− Note −−−−−

696565 Shaft−Throttle

(Plastic)

98 398185 Kit−Idle Speed

(Carburetor)

98A 493280 Kit−Idle Speed

101 691623 Pin−Shaft

(Drive Gear)

101A 262626 Pin−Shaft

(For Rewind Starter)

104 D691242 Pin−Float Hinge

108 691182 Valve−Choke

109 494218 Shaft−Choke

117 494870 Jet−Main

(Standard)

(Used After Code Date

02092900).

−−−−−−− Note −−−−−

498975 Jet−Main

(Standard)

(Used After Code Date

96060200 and Before

Code Date 02093000).

494870 Jet−Main

(Standard)

(Used Before Code

Date 96060300).

494870 Jet−Main

(Standard)

Used on Type No(s).

2368, 2369.

117A 498976 Jet−Main

(Standard)

(Used After Code Date

96060200).

−−−−−−− Note −−−−−

493637 Jet−Main

(Standard)

(Used Before Code

Date 96060300).

K Included in Engine Gasket Set−Ref. No.358.

D Included in Carburetor Overhaul Kit−Ref. No. 121.

z Included in Carburetor Gasket Set−Ref. No. 977.

∅ Included in Valve Gasket Set−Ref. No 1095.

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
