Деталировка двигателя B_S 12J802 Страница: 13

Тарпан ТМЗ-МК-03 [13/16] 13 assemblies include all parts shown in frames 10 31 2007 13

12J800

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0991−13 Assemblies include all parts shown in frames. 10/31/2007

209 699056 Spring−Governor

−−−−−−− Note −−−−−

691833 Spring−

Governor

Used on Type No(s).

1567.

691835 Spring−

Governor

Used on Type No(s).

1120.

691291 Spring−

Governor

Used on Type No(s).

1934, 2935, 3142,

4961.

691851 Spring−

Governor

Used on Type No(s).

0652, 0653, 0818,

0819, 0825, 0826,

0861, 0878, 0879,

1324, 1328, 1330,

1334, 1367, 1370,

1371, 1528, 1535,

1717, 1787, 1918,

1919, 1930, 1936,

1961, 1968, 2372,

2636, 2628, 2635,

2805, 2916, 2919,

3113, 3114, 3131,

3132, 3139.

691292 Spring−

Governor

Used on Type No(s).

0820, 0873, 0874,

0875, 0881, 1123,

1166, 1322, 1325,

1329, 1337, 1338,

1340, 1363, 1366,

1368, 1369. 1522,

1552, 1716, 1753,

1755, 1904, 1905,

1915, 1926, 1927,

1929, 1931, 1973,

1974, 1988, 2327,

2366, 2367, 2368,

2369, 2370, 3104,

3128, 3136, 3140.

691852 Spring−

Governor

Used on Type No(s).

2328, 2329, 2330,

2371.

217 690354 Spring−Choke Return

222 790143 Bracket−Control

(Remote/Manual

Friction)(Primer)

222A 692021 Bracket−Control

(Remote

Choke A Matic,

Non−Compliance)

222B 693006 Bracket−Control

(Fixed Speed)

−−−−−−− Note −−−−−

692467 Bracket−

Control

(Fixed Speed)

Used on Type No(s).

2327, 2328, 2329,

2368, 2369, 3137.

222C 692150 Bracket−Control

(Remote/Manual

Friction)(Variable

Speed And 5 Position

Manual Choke)

222D 791128 Bracket−Control

(Remote/Manual

Friction)

(Variable Speed and 5

Position Manual

Choke, Without

Stopswitch)

227 690783 Lever−Governor

Control

236 691826 Link−Lockout

240 298090S Filter−Fuel

265 690798 Clamp−Casing

265A 691024 Clamp−Casing

267 691044 Screw

(Casing Clamp)

268 691025 Casing−Control Wire

(Cut to Required

Length)

269 690126 Wire−Control

(Cut to Required

Length)

270 691027 Nut

(Control Wire Casing)

271 691028 Lever−Control

276 D

z271716 Washer−Sealing

276A 280973 Washer−Sealing

(For Rewind Starter)

287 690940 Screw

(Dipstick Tube)

300 692038 Muffler

(Super Lo Tone)

300A 494343S Muffler

(Square Lo Tone)

300B 497681 Muffler

(Catalyst)

304 493293 Housing−Blower

(Compliance)

−−−−−−− Note −−−−−

493294 Housing−

Blower

(Non Compliance)

Used on Type No(s).

0818, 0819, 0825,

0826, 0873, 0874,

0875, 0880, 1123,

1324, 1328, 1330,

1331, 1334, 1337,

1367, 1552, 1567,

1717, 1753, 1754,

1755, 1918, 1919,

1925, 1926, 1927,

1931, 1934, 1936,

1973, 1974, 1988,

2367, 2372, 2805,

2905, 2935, 3131,

3136, 3139, 3140,

4961.

694092 Housing−

Blower

Used on Type No(s).

2369.

695892 Housing−

Blower

Used on Type No(s).

1786, 1987, 3129,

3141.

696298 Housing−

Blower

Used on Type No(s).

2327, 2328, 2329.

K Included in Engine Gasket Set−Ref. No.358.

D Included in Carburetor Overhaul Kit−Ref. No. 121.

z Included in Carburetor Gasket Set−Ref. No. 977.

∅ Included in Valve Gasket Set−Ref. No 1095.

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Тарпан ТМЗ-МК-03 [13/16] 13 assemblies include all parts shown in frames 10 31 2007 13
