12J800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0991−14 Assemblies include all parts shown in frames. 10/31/2007
14
305 691108 Screw
(Blower Housing)
306 690450 Shield−Cylinder
307 690345 Screw
(Cylinder Shield)
309 695550 Motor−Starter
(Used Before Code
Date 07052900).
309A 795092 Motor−Starter
(Used After Code Date
07052800).
310 692327 Bolt
(Starter Motor)
332 690662 Nut
(Flywheel)
333 802574 Armature−Magneto
333A 792640 Armature−Magneto
(Screw On Spark Plug
Boot)
−−−−−−− Note −−−−−
793353 Armature−
Magneto
(Snap In Spark Plug
Boot)
334 691061 Screw
(Magneto Armature)
337 802592S Plug−Spark
(Resistor)
−−−−−−− Note −−−−−
697451 Plug−Spark
(EMS)
346 690661 Screw
(Spark Arrestor)
356 692390 Wire−Stop
356A 690650 Wire−Stop
356C 690808 Wire−Stop
357A 692191 Key−Drive Pulley
358 497316 Gasket Set−Engine
363 19069 Flywheel Puller
365 691688 Screw
(Carburetor)
374 691074 Washer
(Camshaft)
383 89838S Wrench−Spark Plug
404 690272 Washer
(Governor Crank)
425A 690670 Screw
(Air Cleaner Cover)
443A 692523 Screw
(Air Cleaner Primer
Base)
445A 491588S Filter−Air Cleaner
Cartridge
455 791960 Cup−Flywheel
455A 224250 Cup−Flywheel
(Straight Side Cup)
456 692299 Plate−Pawl Friction
456A 224321 Plate−Pawl Friction
(Use with
Spring/Dog Kit)
459 281505S Pawl−Ratchet
459A 492833 Pawl−Ratchet
(Use with
Spring/Dog Kit)
474 691991 Alternator
500 691086 Washer
(Key Switch)
505 691251 Nut
(Governor Control
Lever)
510 795093 Drive−Starter
513 692358 Clutch−Drive
520 691084 Terminal−Ground
523 499621 Dipstick
524 K692296 Seal−Dipstick Tube
525 495265 Tube−Dipstick
529 691923 Grommet
544 690786 Armature−Starter
545 492919 Washer Set
(Starter Motor)
562 92613 Bolt
(Governor Control
Lever)
564 690664 Screw
(Control Cover)
564A 691142 Screw
(Control Cover)
578 398153 Wire Assembly
584 697734 Cover−Breather
Passage
585 K691879 Gasket−Breather
Passage
592 690800 Nut
(Rewind Starter)
597 691696 Screw
(Pawl Friction Plate)
601 791850 Clamp−Hose
601A 691038 Clamp−Hose
604 691757 Cover−Control
604A 691344 Cover−Control
608 497680 Starter−Rewind
608A 497598 Starter−Rewind
613 691340 Screw
(Muffler)
613A 691653 Screw
(Muffler)
613B 691114 Screw
(Muffler)
615 690340 Retainer−Governor
Shaft
616 698801 Crank−Governor
617zD270344S Seal−O Ring
(Intake Manifold)
621 692310 Switch−Stop
633 zD691321 Seal−Choke/Throttle
Shaft
635 66538S Boot−Spark Plug
635A 792597 Boot−Spark Plug
(Screw On Style)
−−−−−−− Note −−−−−
793351 Boot−Spark
Plug
(Snap On Style)
651 691660 Screw
(Starter Gear Cover)
664 691087 Nut
(Key Switch)
668 K493823 Spacer
670 692294 Spacer−Fuel Tank
676 396548 Deflector−Muffler
677 690661 Screw
(Muffler Deflector)
678 224278 Spacer−Rewind
684 690345 Screw
(Breather Passage
Cover)
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
