12J800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0991−9 Assemblies include all parts shown in frames. 10/31/2007
9
1 697324 Cylinder Assembly
2 399269 Kit−Bushing/Seal
(Magneto Side)
3 K299819S Seal−Oil
(Magneto Side)
4 493279 Sump−Engine
−−−−−−− Note −−−−−
696294 Sump−Engine
Used on Type No(s).
2327, 2328, 2329.
4A 493365 Sump−Engine
(Auxiliary PTO)
5 691160 Head−Cylinder
7 K∅692249 Gasket−Cylinder Head
8 695250 Breather Assembly
9 K∅699833 Gasket−Breather
10 691125 Screw
(Breather Assembly)
11 691781 Tube−Breather
12 K692232 Gasket−Crankcase
13 690912 Screw
(Cylinder Head)
15 691680 Plug−Oil Drain
(Square Socket)
15A 691093 Plug−Oil Drain
(Hex Socket)
16 691451 Crankshaft
(Used After Code Date
97011200).
−−−−−−− Note −−−−−
694442 Crankshaft
(Used Before Code
Date 97011300).
691450 Crankshaft
(Used After Code Date
97011200).
Used on Type No(s).
0653, 0818, 0819,
0825, 0881, 1324,
1328, 1330, 1331,
1337, 1363, 1367,
1370, 1371, 1522,
1528, 1535, 1787,
1918, 1919, 1936,
2372, 2628, 2635,
2825, 2919, 2925,
3113, 3114, 3131.
694440 Crankshaft
(Used Before Code
Date 97011300).
Used on Type No(s).
1522, 1528, 1535,
2825.
692978 Crankshaft
(Used After Code Date
97011200).
Used on Type No(s).
0652, 0861, 1961,
1968, 1978.
690793 Crankshaft
(Used Before Code
Date 97011300).
Used on Type No(s).
0861, 1961.
693017 Crankshaft
(Used After Code Date
97011200).
Used on Type No(s).
2824.
694441 Crankshaft
(Used Before Code
Date 97011300).
Used on Type No(s).
2824.
691452 Crankshaft
(Used After Code Date
97011200).
Used on Type No(s).
0874, 0875, 1120,
1122, 1123, 1166,
1366, 1567, 1753,
1754, 1755, 1904,
1905, 1917, 1925,
1927, 1929, 1974,
2322, 2325, 2326,
2327, 2328, 2329,
2330, 2366, 2367,
2371, 2636, 2816,
2916, 3104, 3136.
694059 Crankshaft
(Used Before Code
Date 97011300).
Used on Type No(s).
0875, 1120, 1166,
2816.
691454 Crankshaft
(Used After Code Date
97011200).
Used on Type No(s).
0878, 1338, 2826,
2926.
692000 Crankshaft
(Used Before Code
Date 97011300).
Used on Type No(s).
2826.
691455 Crankshaft
(Used After Code Date
97011200).
Used on Type No(s).
1966, 2818, 2918,
3125.
691375 Crankshaft
(Used Before Code
Date 97011300).
Used on Type No(s).
2818.
694079 Crankshaft
Used on Type No(s).
2368.
696337 Crankshaft
Used on Type No(s).
1753.
696009 Crankshaft
Used on Type No(s).
2369, 2370.
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
