12J800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0991−15 Assemblies include all parts shown in frames. 10/31/2007
15
689 691855 Spring−Friction
689A 262625 Spring−Friction
692 690572 Spring−Detent
697 691127 Screw
(Drive Cap)
715 691147 Screw
(Stop Shaft)
718 690959 Pin−Locating
721 690449 Stop−Shaft
741 790345 Gear−Timing
(Use Without Woodruff
Key)
−−−−−−− Note −−−−−
691830 Gear−Timing
(Uses Woodruff Key)
742 93941 Retainer−E Ring
743 690516 Gear−Drive
(Clockwise)
Used on Type No(s).
0818, 1322, 1331,
1918, 2850, 2950.
−−−−−−− Note −−−−−
691772 Gear−Drive
(Counterclockwise)
Used on Type No(s).
0826, 1325, 1326,
1333, 1338, 1340,
1369, 1550, 1936,
1969, 2650, 2851,
2951, 2981, 3126.
745 691648 Screw
(Brake)
783 691918 Gear−Pinion
(19 Teeth)
(Srarter Drive)
783A 691269 Gear−Pinion
(12 Teeth)
784 795095 Cover−Starter Gear
785 692352 Gasket−Starter Cover
789A 691372 Harness−Wiring
(Used Before Code
Date 00040700).
789B 696547 Harness−Wiring
(Used After Code Date
00040600).
801 690782 Cap−Drive
802 695267 Cap−End
(Used After Code Date
00040600).
−−−−−−− Note −−−−−
695975 Cap−End
(Used Before Code
Date 00040700).
803 695266 Housing−Starter
(Used After Code Date
00040600).
−−−−−−− Note −−−−−
695975 Housing−
Starter
(Used Before Code
Date 00040700).
832B 497683 Guard−Muffler
832D 499034 Guard−Muffler
836 690664 Screw
(Muffler Guard)
836B 691147 Screw
(Muffler Guard)
842 K691031 Seal−O Ring
(Dipstick Tube)
843 691884 Sleeve−Lever
847 692047 Dipstick/Tube
Assembly
851 493880S Terminal−Spark Plug
851A 692424 Terminal−Spark Plug
853 695268 Adapter−Wire
868 697338 Seal−Valve
869 691155 Seat−Valve
(Intake)
870 690380 Seat−Valve
(Exhaust)
871 262001 Bushing−Valve Guide
(Exhaust)
−−−−−−− Note −−−−−
63709 Bushing−Valve
Guide
(Intake)
883 K∅691881 Gasket−Exhaust
892 690646 Switch−Key
910 691094 Stud
(Alternator)
921 497233 Cover−Blower Housing
921A 695886 Cover−Blower Housing
921B 692932 Cover−Blower Housing
(Red)
−−−−−−− Note −−−−−
692931 Cover−Blower
Housing
(Black)
921C 695889 Cover−Blower Housing
921E 696262 Cover−Blower Housing
921H 790037 Cover−Blower Housing
921K 699984 Cover−Blower Housing
922 691831 Spring−Brake
−−−−−−− Note −−−−−
692135 Spring−Brake
Used on Type No(s).
1987.
923 691994 Brake
−−−−−−− Note −−−−−
695891 Brake
Used on Type No(s).
1987.
925 690595 Cover−Linkage
930 691919 Guard−Rewind
930A 691345 Guard−Rewind
935 499421 Switch−Interlock
937 691325 Spline−Starter
946 691738 Stop−Rope
957A 692046 Cap−Fuel Tank
(Plastic)
957B 699985 Cap−Fuel Tank
(Plastic)
966A 496116 Base−Air Cleaner
Primer
967A 493537S Filter−Pre Cleaner
968B 692298 Cover−Air Cleaner
969 690700 Screw
(Blower Housing
Cover)
969A 691138 Screw
(Blower Housing
Cover)
970 691681 Screw
(Air Cleaner Primer
Bracket)
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
