12J800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0991−16 Assemblies include all parts shown in frames. 10/31/2007
16
972 699392 Tank−Fuel
(Plastic)
972B 699374 Tank−Fuel
(Plastic)
−−−−−−− Note −−−−−
695960 Tank−Fuel
(Plastic)
Used on Type No(s).
2327, 2328, 2329.
975 493640 Bowl−Float
976 694395 Primer−Carburetor
977 498261 Gasket Set−Carburetor
990 691959 Key Set
990A 695951 Key Set
(Touch N Mow)
994 398067 Arrestor−Spark
1005 691346 Fan−Flywheel
1009 696255 Screw
(Starter Motor)
1019 494256 Kit−Label
−−−−−−− Note −−−−−
790231 Kit−Label
(Touch N Mow)
1036 Label−Emissions
(Available From A
Briggs & Statton
Authorized Dealer)
1058 277039 Operator’s Manual
1059 692311 Kit−Screw/Washer
−−−−−−− Note −−−−−
696293 Kit−Screw/
Washer
(Touch N Mow)
1095 498528 Gasket Set−Valve
1119 691648 Screw
(Alternator)
1134 224322 Washer
(Pawl Friction Plate)
1160 690345 Screw
(Interlock Switch)
1210 498144 Pulley/Spring
Assembly
(Pulley)
1211 498144 Pulley/Spring
Assembly
(Spring)
1236 695959 Starter−Mechanical
(Touch N Mow)
(Do Not Service
Individual Parts,
Only As A Whole)
1319 794467 Label−Warning
1330 270962 Manual−Repair
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
