Деталировка двигателя B_S 12J802 Страница: 12

Тарпан ТМЗ-МК-03 [12/16] 12 assemblies include all parts shown in frames 10 31 2007 12

12J800

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0991−12 Assemblies include all parts shown in frames. 10/31/2007

118 497315 Jet−Main

(High Altitude)

(Used After Code Date

02092900).

−−−−−−− Note −−−−−

497348 Jet−Main

(High Altitude)

(Used After Code Date

96060200 and Before

Code Date 02093000).

497315 Jet−Main

(High Altitude)

(Used Before Code

Date 96060300).

497315 Jet−Main

(High Altitude)

Used on Type No(s).

2368, 2369.

118A 498977 Jet−Main

(High Altitude)

(Used After Code Date

96060200).

−−−−−−− Note −−−−−

496063 Jet−Main

(High Altitude)

(Used Before Code

Date 96060300).

121 498260 Kit−Carburetor

Overhaul

125 698444 Carburetor

(Primer System)

(Used After Code Date

96060200).

−−−−−−− Note −−−−−

498170 Carburetor

(Primer System)

(Used After Code Date

95102900 and Before

Code Date 96060300).

498254 Carburetor

(Primer System)

(Used Before Code

Date 95103000).

694146 Carburetor

Used on Type No(s).

2368, 2369.

125A 498964 Carburetor

(Choke System)

Used on Type No(s).

1120, 1567.

−−−−−−− Note −−−−−

690000 Carburetor

(Choke System)

Used on Type No(s).

2905.

127 D694468 Plug−Welch

127A D691739 Plug−Welch

130 691203 Valve−Throttle

−−−−−−− Note −−−−−

696564 Valve−Throttle

(Used With Plastic

Throttle Shaft)

130A 691181 Valve−Throttle

133 398187 Float−Carburetor

134 D398188 Kit−Needle/Seat

137 zD693981 Gasket−Float Bowl

144 493824 Pulley/Spring

Assembly

146 690979 Key−Timing

159 691753 Bracket−Air Cleaner

Primer

163KzD272653 Gasket−Air Cleaner

187 791766 Line−Fuel

(Cut to Required

Length)

187A 791873 Line−Fuel

(Molded)

187B 791891 Line−Fuel

(Includes Filter)

(Used After Code Date

05063000).

−−−−−−− Note −−−−−

692042 Line−Fuel

(Includes Filter)

(Used Before Code

Date 05070100).

187C 791875 Line−Fuel

(Molded)

188 690877 Screw

(Control Bracket)

190 690940 Screw

(Fuel Tank)

202 691829 Link−Mechanical

Governor

K Included in Engine Gasket Set−Ref. No.358.

D Included in Carburetor Overhaul Kit−Ref. No. 121.

z Included in Carburetor Gasket Set−Ref. No. 977.

∅ Included in Valve Gasket Set−Ref. No 1095.

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
