Thermal Operation and Configuration Requirements
To keep the system operating within supported maximum thermal limits, the system must meet the following operating and
configuration guidelines:
• Ambient inlet temperature cannot exceed 35º C and should not remain at this maximum level for long periods of time.
Doing so may affect long term reliability of the system.
• The CPU-1 processor + CPU heatsink must be installed first. The CPU-2 heatsink must be installed at all times,
with or without a processor installed.
• Memory Slot population requirements:
NOTE: Specified memory slots can be populated with a DIMM or supplied DIMM Blank. Memory population rules apply
when installing DIMMs.
– DIMM Population Rules on CPU-1
Install DIMMs in order: Channels A, B, C, and D. Start with 1
st
DIMM slot (blue) on each channel, then slot 2, then
slot 3 (24 DIMM board). Only remove DIMM blanks when populating the slot with a DIMM.
– DIMM Population on CPU-2
Install DIMMs in order: Channels E, F, G, and H. Start with 1
st
DIMM slot (blue) on each channel, then slot 2, then
slot 3 (24 DIMM board). Only remove DIMM blanks when populating the slot with a DIMM.
The following system configurations require the specific memory slots be populated at all times using a DIMM or
supplied DIMM blank.
– System Configuration: 8x 2.5" hard drive bay configuration + 24 DIMM server board
DIMM blanks installed on memory slot 3 for all memory channels.
• All hard drive bays must be populated. Hard drive carriers either can be populated with a hard drive or supplied
drive blank.
• The air duct must be installed at all times.
• In single power supply configurations, the second power supply bay must have the supplied filler blank installed
at all times.
• The system top-cover must be installed at all times. The only exception to this requirement is to hot replace a failed
system fan, in which case the top cover can be removed for no more than three minutes at a time.
