General Installation Process

Install Memory Modules ... Continued

To Install DIMMs:

Open both DIMM socket levers.

Note location of alignment notch.

CAUTION: Avoid touching contacts

when handling or installing DIMMs.

IMPORTANT! Visually check that each latch is fully closed and correctly engaged with

each DIMM edge slot.

Push down ﬁrmly on the DIMM until it snaps into place and both levers close.

Insert DIMM making sure the connector edge of the DIMM aligns correctly with the slot.

2.5" HDD

Install

Hard Drives

2.5" Hard Drive Carrier (For system with 2.5" hard drive bay only)

Hard Drive Numbering Diagram

Drive 0 Primary

8 x 2.5" hard drive bay as shown

Remove the drive carrier by pressing the

green

latch

to unlock.

Pull out the black lever and slide the carrier out.

Remove the four screws from the 2.5" HDD carrier.

Disengage and remove the plastic drive blank

from the HDD carrier.

Install the hard disk drive using the four screws as shown. Make sure

the connector end of the drive matches the backplane connector.

With the lever open, insert the hard disk drive assembly into the chassis,

then push in the lever to lock it into place.

CAUTION: If you don't install

all drives, empty drive bays

must be occupied by carriers

with plastic drive blank

provided to maintain proper

system cooling.
