1
System Overview
* 2.5" Hard Drive Bay system as shown
System Features and Components
Hot Swap
Hard Drive Bays
CPU2
Air Duct
Front Control Panel
PCI Riser
1+1 Redundant
Power Supply
Modules
Server Board
System Fans
CPU1
Intel® Server System R1000GZ/GL Product Family
Useful Information:
• Riser Slot 2 is not functional without having two processors installed.
• The SCU1 (4-7) port requires an Intel
®
RAID C600 Upgrade Key installed to be functional.
