Karcher BD 80/120 W Bp [19/244] Accessories
- 8
– Only use accessories and spare parts
which have been approved by the man-
ufacturer. The exclusive use of original
accessories and original spare parts
ensures that the appliance can be oper-
ated safely and troublefree.
– At the end of the operating instructions
you will find a selected list of spare
parts that are often required.
– For additional information about spare
parts, please go to the Service section
at www.kaercher.com.
The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within the warranty period
free of charge, provided that such failure is
caused by faulty material or defects in man-
ufacturing. In the event of a warranty claim
please contact your dealer or the nearest
authorized Customer Service centre.
Please submit the proof of purchase.
Accessories
Description Part no.: Description Piece Machine
requires
piece
Disk brush, white 8.600-032.0 For polishing floors. 1 2
Disk brush, red (medium, standard) 8.600-030.0 For cleaning slightly dirtied or sensitive floors. 1 2
Disk brush, black 8.600-034.0 For cleaning heavily dirtied floors. 1 2
Specifications
Power
Nominal voltage V36
Battery capacity (Pack model) Ah (5h) 200
Average power consumption W 2160
Drive motor output (rated output) W560
Suction engine output W560
Brush engine output W2x560
Type of protection IP X4
Vacuuming
Cleaning power, air quantity l/s 31,4
Cleaning power, negative pressure kPa 15
Cleaning brushes
Working width mm 810
Brush diameter mm 410
Brush speed 1/min 200
Dimensions and weights
Drive speed (max.) km/h 5,2
Climbing capability (max.) %2
Theoretical surface cleaning performance m²/h 3300
Fresh/dirt water reservoir volume l 120/120
Max. water temperature °C 60
Permissible overall weight kg 694
Transport weight kg 574
Surface load kPa 441
Length mm 1800
Width mm 990
Height mm 1170
Values determined as per EN 60335-2-72
Vibration total value on arms m/s
2
<2,5
Uncertainty K m/s
2
0,5
Sound pressure level L
pA
dB(A) 75
Uncertainty K
pA
dB(A) 3
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 93
Spare parts Warranty
19EN
