Attention:

- The ‘protection indicator light’ will be on after a long time operation, it shows that the inner

temperature is over the permitted data, then the machine should be stopped using for some time to

let it cool down. It can continue using after the ‘protection indicator light’is off.

The power source should be switched off after the operation or while temporarily leaving job site.

Welders should dress canvas work cloth and wear welding mask to prevent the hurt from arc and

thermal radiation.

Light separating screen should be put in the job site to prevent the arc will hurt other people.

Inflammable or explosive materials are prohibited to access the job site.

Each connection of the welder should be connected correctly and creditably.

Wire, groove and surrounding 10-20 mm site must be cleaned, no existing rust, greasy dirt, water

and paint etc.

a) Debugging before welding

Install the torch, gas and welding wire, and then turn on the power switch. The power indicator is on

and fan works.

Turn on the gas regulator of gas tank, the gas pressure is shown on the meter

Turn the gas regulator anticlockwise, loose the wire roller, press down the torch switch, and then

adjust the gas flow to meet the technics requirement, and then repress the wire roller

Press the torch switch till the wire extends to the nozzle

When wire feeding, make the cable straight.

When wire feeding, make sure the wire is located on the wire roller groove reliably and the feeding

speed should be smooth. If the wire feeding speed is not smooth, please adjust the tension of the

wire roller.

When using MIG wire, the V groove wire roller should be used.

b) Welding

When welding, please adjust the welding current and welding voltage matchable according to the

set-up

Aim at the welding line, press down the torch switch, the wire feeds automatically. The arc is started

once the wire is touched the work piece. When welding, the “working indicator” is on

a) Debugging before welding

Change the polarity on the vertical board, it is, connect MIG torch lead to “-”, the ground cable lead

to “+”.

Install the torch, gas and welding wire, and then turn on the power switch. The power indicator is on

and fan works.

Press the torch switch till the wire extends to the nozzle

When wire feeding, make the cable straight.

When wire feeding, make sure the wire is located on the wire roller groove reliably and the feeding

speed should be smooth. If the wire feeding speed is not smooth, please adjust the tension of the

wire roller.

When using flux wire, the gear type groove wire roller should be used.

b) Welding

When welding, please adjust the welding current and welding voltage matchable according to the

set-up

Aim at the welding line, press down the torch switch, the wire feeds automatically. The arc is started

once the wire is touched the work piece. When welding, the “working indicator” is on

- .

Work Piece cleaning Before Welding

MIG welding steps

Flux welding steps

www.fubag.ru

Omperator's anual

--10
