2. Technical Specification

The manufacturer reserves himself the right to make the manual's content or welder's function

change without any preliminary notification of the users.

3. Description

MIG Series Inverter is designed to be used with the advanced IGBT (Insulated Gate Bipolar Tube)

and rapid recovery diode as its main control and transfer components and assisted with the

specially developed control circuit. The continuous wire can form welding seam metal after melting

so as to connect the wok pieces each other. The melting electrode gas protects the welding district

easily, so it is easy to operate & observe the whole working process. Its characteristics are high

produce efficiency and easy to carry out all-position welding.

The highlighted characteristics of MIG Series Inverter:

Featured with small volume and light weight, it widely used in upholstering field, repairing field and

fieldwork.

High working efficiency.Automatic Wire Feeding can realize high speed welding.

No special requirements for the welding wire. Both solid and flux-cored wires are available.The

diameter of the wire is between 0 6 0,8 (1 0)

ndercutfunction make arc-piloting more successful.

, - , mm.

-U

www.fubag.ru

Omperator's anual

--3

Item IRMIG140 IRMIG160 IRMIG180

Rated input voltage, V 220

Frequency, Hz 50

Rated input current, А 25 28 30

Rated input, kVA 5,5 6,2 6,6

Rated no-load voltage, V 52 52 52

MIG min welding current, А 30 30 30

MIG max welding current, А 140 160 180

MIG rated duty cycle, % 35 30 25

MIG welding current at 100%, А 83 88 90

Efficiency, % 85 85 85

Power factor 0,92 0,92 0,75

Insulation class H

Enclosure protection IP21S

Cooling type Fan cooled

Dimension (LхWхH), mm 570x300x370

Weight, kg 11 11 12
