![Asus PRIME Z270-K [6/76] Package contents](/views2/1233067/page6/bg6.png)
vi
PRIME Z270-K specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS PRIME Z270-K motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x ASUS Q-Shield
2 x M.2 screws
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
Specications
CPU
LGA1151 socket for Intel
®
7th/6th Generation Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
Z270 Chipset
Memory
4 x DIMMs, max. 64GB, DDR4 3866(O.C.)*/ 3733(O.C.)*/ 3600(O.C.)*/
3466(O.C.)*/ 3400(O.C.)*/ 3333(O.C.)*/ 3300(O.C.)*/ 3200(O.C.)*/ 3000(O.C.)*/
2800(O.C.)*/ 2666(O.C.)*/ 2400(O.C.)*/ 2133 MHz, non-ECC, un-buffered
memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* The maximum memory frequency supported varies by processor.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
1 x PCI Express 3.0/2.0 x16 slot (max. at x4 mode, compatible with PCIe x1, x2
and x4 devices)
2 x PCI Express 3.0/2.0 x1 slots
2 x PCI slots
Multi-GPU
Support
Supports AMD
®
Quad-GPU CrossFireX™ Technology
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI, DVI-D, RGB ports
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160 @ 24Hz / 2560
x 1600@60Hz
- Supports DVI-D with maximum resolution of 1920 x 1200 @ 60Hz
- Supports RGB with maximum resolution of 1920 x 1200 @ 60Hz
Supports Intel
®
InTru
TM
3D, Quick Sync Video, Intel
®
Clear Video HD Technology,
and Intel
®
Insider
TM
Maximum shared memory of 1024 MB (for iGPU exclusively)
Supports up to three displays simultaneously
