ix
PRIME Z270-K specications summary
(continued on the next page)
Specications
Rear panel I/O
ports
1 x PS/2 keyboard/mouse combo port
1 x HDMI port
1 x DVI-D port
1 x RGB port
1 x LAN (RJ-45) port
2 x 10Gb/s USB 3.1/3.0/2.0 ports (teal blue, Type A)
1 x 5Gb/s USB Type C port
2 x USB 3.0/2.0 ports (blue, type A)
2 x USB 2.0/1.1 ports
3 x Audio jacks support 8-channel audio output*
* Use a chassis with HD audio module in the front panel to support a 8-channel audio
output.
Internal
connectors
2 x USB 3.0 / 2.0 connector support additional 4 USB 3.0 / 2.0 ports (19-pin)
2 x USB 2.0 / 1.1 connectors support additional 4 USB 2.0 / 1.1 ports
6 x SATA 6.0 Gb/s connectors (gray)
2 x M.2 Socket 3 (for M Key)
1 x 4-pin CPU Fan connector for both 3-pin (DC mode) and 4-pin (PWM mode)
CPU coolers control*
2 x 4-pin Chassis Fan connectors for 3-pin (DC mode) and 4-pin (PWM mode)
coolers control*
1 x AIO Pump Fan header
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x S/PDIF out header
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x COM connector
1 x Clear CMOS header
* By default, the CPU/Chassis Q-Fan control setting is set to Auto mode, which detects
the CPU and chassis fans installed and changes the control mode automatically.
BIOS features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI
6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning
Wizard, F6 Qfan Control, F3 My Favorites, Last Modied log, F12 PrintScreen and
ASUS DRAM SPD (Serial Presence Detect) memory information
Manageability
WfM 2.0, DMI 3.0, WOL by PME, PXE
