1-6
Chapter 1: Product introduction
4. Center / Subwoofer port (orange).Thisportconnectsthecenter/subwooferspeakers.
5. Rear Speaker Out port (black).Thisportconnectstherearspeakersina4.1channel,
5.1channel,or7.1channelaudioconguration.
6. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother
audiosources.
7. Line Out port (lime). Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1,
and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.
8. Microphone port (pink).Thisportconnectstoamicrophone.
9. Side Speaker Out port (gray). Thisportconnectstothesidespeakersina
7.1-channelaudioconguration.
Refertotheaudiocongurationtableforthefunctionoftheaudioportsin2.1,4.1,5.1,or
7.1-channelconguration.
LAN port
Speed
LED
Activity Link
LED
Activity/Link LED Speed LED
Status Description Status Description
Off Nolink OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange
(Blinking)
Dataactivity GREEN 1Gbpsconnection
Orange
(Blinkingthen
steady)
Readytowake
upfromS5mode
1. PS/2 Mouse/Keyboard combo port.ThisportconnectstoaPS/2mouseorPS/2
keyboard.
2. Video Graphics Adapter (VGA) port.This15-pinportisforaVGAmonitororother
VGA-compatibledevices.
3. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)
throughanetworkhub.
LAN port LED indications
2
3
10
13 12
1
14
11
4 5 6 7
89
1.2.2 Rear panel connectors
