Asus PRIME B250M-PLUS [7/28] Prime b250m plus specifications summary
![Asus PRIME B250M-PLUS [7/28] Prime b250m plus specifications summary](/views2/1233076/page7/bg7.png)
vii
PRIME B250M-PLUS specications summary
(continued on the next page)
Storage
Intel
®
B250 Chipset with Intel
®
Rapid Storage Technology 15 support:
- 1 x M.2_1 Socket 3 with M Key, type 2242/2260/2280 storage devices
support (both SATA and PCIe x2 mode)*
- 1 x M.2_2 Socket 3 with M Key, type 2242/2260/2280 storage devices
support (IRST support, PCIe x4 mode)**
- 6 x SATA 6.0 Gb/s ports (gray)
- Intel
®
Optane™ Memory Ready***
* When a device in SATA mode is installed on the M.2_1 socket, SATA_1 port cannot
be used.
** Only M.2_2 socket can support Intel
®
Optane™ Memory.
*** Intel
®
Optane™ Technology is only supported when using 7th Generation Intel
®
processors. Before using Intel
®
Optane™ memory modules, ensure that you have
updated your motherboard drivers and BIOS to the latest version from ASUS support
website.
LAN
Intel
®
I219-V Gigabit LAN
- Dual interconnection between the integrated Media Access Controller (MAC)
and physical layer (PHY)
Audio
Realtek
®
ALC887 8-channel High Denition Audio CODEC
- LED-illuminated design: Brighten up your build with the gorgeous illuminated
audio trace path
- Audio Shielding: Ensures precision analog/digital separation and greatly
reduced multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to
guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive
sound with exceptional clarity and delity
- Supports Jack-Detection and Front Panel Jack-Retasking
USB
Intel
®
B250 Chipset
- 1 x 5Gb/s USB Type C port (at back panel) support 3A power output
- 5 x USB 3.0/2.0 ports (2 ports at mid-board; 3 ports at back panel, blue,
Type A)
- 6 x USB 2.0/1.1 ports (4 ports at mid-board; 2 ports at back panel)
ASUS special
features
ASUS 5X PROTECTION III
- ASUS SafeSlot Core: Fortied PCIe Slot prevents damage
- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-
electricity discharges
- ASUS Overvoltage Protection: World-class circuit-protecting power design
- ASUS Stainless Steel Back I/O: 3X corrosion-resistance for greater durability
- ASUS DIGI+ VRM: 6 Phase digital power design
Superb Performance
M.2 onboard
- The latest transfer technologies with up to 32Gb/s data transfer speeds
ASUS Fan Xpert 2+
- Advanced fan controls for ultimate cooling and quietness
ASUS EPU
- EPU
UEFI BIOS
- Most advanced options with fast response time
E12098_PRIME_B250M-PLUS_UM.indb 7 2016-11-07 17:34:19
