viii
PRIME B250M-PLUS specications summary
(continued on the next page)
ASUS special
features
Gaming Scenario
Audio Features
- Audio that roars on the battleeld
ASUS Exclusive Features
- ASUS AI Charger
- ASUS AI Suite 3
EZ DIY
UEFI BIOS EZ Mode
- Featuring friendly graphics user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
Q-Design
- ASUS Q-DIMM
- ASUS Q-Slot
ASUS Quiet
Thermal
Solution
Quiet Thermal Design
- ASUS Fan Xpert 2+
- Stylish Fanless Design: MOS Heat-sink and PCH Heat-sink solution
Rear panel I/O
ports
1 x PS/2 keyboard/mouse combo port
1 x HDMI port
1 x DVI-D port
1 x D-Sub port
1 x LAN (RJ-45) port
1 x USB 5Gb/s Type C port
3 x USB 3.0/2.0 ports (blue, Type A)
2 x USB 2.0/1.1 ports
6-Jack 8-Channel Audio I/O ports
Internal
connectors
1 x USB 3.0/2.0 connector supports additional 2 USB ports (19-pin)
2 x USB 2.0/1.1 connectors support additional 4 USB ports
2 x M.2 Socket 3 (for M Key)
6 x SATA 6.0Gb/s connectors (gray)
1 x 4-pin CPU Fan connector for 4-pin (PWM mode) coolers control*
2 x 4-pin Chassis Fan connectors for both 3-pin (DC mode) and 4-pin (PWM
mode) coolers control*
1 x Front panel audio connector(AAFP)
1 x System panel connector
1 x S/PDIF out header
1 x 24-pin EATX Power connector
1 x 4-pin ATX 12V Power connector
1 x COM header
1 x Clear CMOS header
BIOS
128Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI
6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan
Control, F3 My Favorites, Last Modied log, F12 PrintScreen, and ASUS
DRAM SPD (Serial Presence Detect) memory information
E12098_PRIME_B250M-PLUS_UM.indb 8 2016-11-07 17:34:19
