vi
PRIME B250M-PLUS specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS PRIME B250M-PLUS motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield, 2 x M.2 screws
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for Intel
®
7th/6th Generation Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
B250 Chipset
Memory
4 x DIMMs, maximum 64GB, DDR4 2400*/2133**MHz, non-ECC, un-buffered
memory***
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Due to Intel
®
chipset limitation, DDR4 2400MHz memory frequency is only supported
by 7th Generation Intel
®
processors. Higher memory modules will run at the maximum
transfer rate of DDR4 2400MHz.
** Due to Intel
®
chipset limitation, DDR4 2133MHz and higher memory modules on 6th
Generation Intel
®
processors will run at the maximum transfer rate of DDR4 2133MHz.
*** Refer to www.asus.com for the Memory QVL(Qualied Vendors List)
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (gray, at x16 mode)
1 x PCI Express 3.0/2.0 x16 slot (black, at x4 mode)
1 x PCI Express 3.0/2.0 x1 slot
Multi-GPU
Support
Supports AMD
®
CrossFireX™ Technology
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI/DVI-D/D-Sub ports
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160 @ 24Hz /
2560 x 1600 @ 60Hz
- Supports DVI-D with maximum resolution of 1920 x 1200 @ 60Hz
- Supports D-Sub with maximum resolution of 1920 x 1200 @ 60Hz
Support Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD Technology/
Insider™
Support up to three displays simultaneously
Maximum shared memory of 1024 MB (for iGPU exclusively)
E12098_PRIME_B250M-PLUS_UM.indb 6 2016-11-07 17:34:19
