(continued on the next page)
STRIX B250F GAMING specications summary
ROG Exclusive
Features
ROG RAMCache II
ROG GameFirst IV*
ROG Overwolf
ROG CPU-Z
ROG CloneDrive
* ROG GameFirst IV is only available for Windows
®
10/8.1 64-bit.
ASUS Special
Features
Performance Optimization
- DIGI + VRM
- GPU Boost
- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control
- AI Suite 3
Gamers Guardian
- SafeSlot
- DIGI+ VRM
- DRAM Overcurrent Protection
- ESD Guards on LAN, Audio, KBMS, and USB3.0/2.0 ports
- Highly Durable Components
- Stainless Steel Back I/O
ASUS EZ DIY
- ASUS EZ Flash 3
- ASUS CrashFree BIOS 3
ASUS Q-Design
- Q-Shield
- Q-LED (CPU, DRAM, VGA, Boot Device LED)
- Q-Slot
- Q-DIMM
ASUS Exclusive Features
- AURA Lightning Control
- 3D Printing Friendly Design
- AI Charger
Internal I/O
connectors
2 x USB 3.0 connectors support additional 4 USB 3.0 ports
1 x USB 2.0 connector supports additional 2 USB 2.0 ports (one connector
via ROG_EXT header)
6 x SATA 6Gb/s connectors
1 x ROG extension (ROG_EXT) header
1 x 4-Pin AIO_PUMP fan connector
1 x 4-Pin CPU fan connector
1 x 4-Pin CPU_OPT fan connector
2 x 4-Pin Chassis fan connectors
1 x 5-Pin Extension fan connector
1 x 24-pin EATX power connector
