ix
(continued on the next page)
STRIX B250F GAMING specications summary
Rear Panel I/O
Ports
2 x USB3.1 ports (1 x typeA [red] and 1 x Type C)
4 x USB2.0 ports
1 x DVI port
1 x HDMI port
1 x DP port
1 x PS/2 keyboard/mouse combo port
2 x USB 3.0 ports [blue]
1 x Anti-surge LAN (RJ45) port
5 x Audio jacks
1 x Optical S/PDIF out
Storage
Intel
®
B250 Chipset with Intel
®
Rapid Storage Technology 15 support
- 6 x SATA 6Gb/s ports
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (SATA mode)*
- 1 x M.2_2 Socket 3 with M key, type 2242/2260/2280/22110 storage
devices support (PCIE 3.0 x 4 mode), supports Intel
®
Optane™ Memory**
* The M.2_1 socket shares SATA_1 port when using M.2 SATA mode device.
Adjust BIOS settings to use a SATA device.
** Intel
®
Optane™ Technology is only supported when using 7th Generation Intel
®
Processors. Before using Intel
®
Optane™ memory modules, ensure that you
have updated your motherboard drivers and BIOS to the latest version from
ASUS support website.
Audio
SupremeFX S1220A 8-Channel High Denition Audio CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113dB SNR recording
input
- SupremeFX Shielding Technology
- Dual Headpone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features
- Sonic Radar III
- Sonic Studio III
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-channel audio and due to Windows
®
7 limitations, 32-bit playback is
unavailable for Windows
®
7.
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst Technology
