ASUS STRIX B250F GAMING
1-7
Chapter 1
1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
cause you physical injury and damage motherboard components.
Slot No. Slot Description
1 PCIex1_1slot
2 PCIex16_1slot
3 PCIex1_2slot
4 PCIex16_2slot
5 PCIex1_3slot
6 PCIex1_4slot
STRIX B250F GAMING
PCIEX16_1
PCIEX16_2
PCIEX1_2
PCIEX1_3
PCIEX1_4
PCIEX1_1
