(continued on the next page)
STRIX Z270I GAMING specications summary
Rear Panel I/O
Ports
1 x DisplayPort
1 x HDMI port
1 x LAN (RJ45) port
4 x USB3.0 ports (3 x Type-A [blue] and 1 x Type-C ports at back panel)
4 x USB 2.0 ports
1 x Optical S/PDIF out
5 x Audio jacks
1 x ASUS Wi-Fi module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.1)
Storage
Intel
®
Z270 Chipset with with RAID 0, 1, 5, 10 and Intel
®
Rapid Storage
Technology 15 support
- 4 x SATA 6Gb/s ports
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (both SATA & PCIE 3.0 x 4 modes)*
- 1 x M.2_2 Socket 3 with M key, type 2242/2260/2280 storage devices
support (PCIE 3.0 x 4 mode)*
- Supports Intel
®
Smart Response Technology**
- Intel
®
Optane™ Memory Ready***
* For a 2242 storage device, use the bundled 2242 mounting kit.
** This function will work depending on the CPU installed.
*** Intel
®
Optane™ Technology is only supported when using 7th Generation Intel
®
Processors. Before using Intel
®
Optane™ memory modules, ensure that you
have updated your motherboard drivers and BIOS to the latest version from
ASUS support website.
Audio
ROG SupremeFX S1220A 8-Channel High Denition Audio CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113dB SNR recording
input
- SupremeFX Shielding Technology
- Dual Headpone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features
- Sonic Radar III
- Sonic Studio III
* Due to limitations in HDA bandwidth, 32-bit/192kHz is not supported for
8-Channel audio and due to Windows
®
7 limitations, 32-bit playback is
unavailable for Windows
®
7.
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst Technology
