1-8
Chapter 1: Product Introduction
Chapter 1
1.1.6 Headers
1. Clear RTC RAM (2-pin CLRTC)
ThisheaderallowsyoutocleartheCMOSRTCRAMdataofthesystemsetup
informationsuchasdate,time,andsystempasswords.
ToerasetheRTCRAM:
1. TurnOFFthecomputerandunplugthepowercord.
2. Useametalobjectsuchasascrewdrivertoshortthetwopins.
3. PlugthepowercordandturnONthecomputer.
4. Holddownthe<Del>keyduringthebootprocessandenterBIOSsetuptore-enter
data.
Ifthestepsabovedonothelp,removetheonboardbatteryandshortthetwopinsagainto
cleartheCMOSRTCRAMdata.AfterclearingtheCMOS,reinstallthebattery.
2. RTC Battery header (2-pin BATT_CON)
ThisheaderisforthelithiumCMOSbattery.
STRIX Z270I GAMING Clear RTC RAM
CLRTC
+3V_BAT
GND
PIN 1
STRIX Z270I GAMING Battery header
PIN 1
GND
VBAT
BATT_CON
