Asus ROG STRIX Z270I Gaming [42/95] Front i o connector

2-10

Chapter 2: Basic Installation

Chapter 2

2.1.7 Front I/O connector

AAFP

To install front panel audio connector

USB 3.0

To install USB 3.0 connector

To install front panel connector

2.1.8 Expansion card installation

To install PCIe x16 cards

USB 3.1

To install USB 3.1 connector
