STRIX Z270I GAMING specications summary
Internal I/O
connectors
1 x 4-pin CPU fan connector
1 x 4-pin Chassis fan connector
1 x 4-pin AIO pump header
1 x Front panel audio connector (AAFP)
1 x USB 3.1 front panel connector
1 x USB 3.0 connector supports additional 2 USB 3.0 ports
1 x 8-pin ATX 12V Power connector
1 x 24-pin EATX Power connector
1 x 14-1 pin TPM connector
1 x 2-pin Clear CMOS/RTC
1 x 2-pin Thermal sensor connector
1 x RGB Header
1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (both SATA & PCIE 3.0 x 4 modes)*
1 x M.2_2 Socket 3 with M key, type 2242/2260/2280 storage devices
support (PCIE 3.0 x 4 mode)*
4 x SATA 6Gb/s connectors
1 x System panel connector
* For a 2242 storage device, use the bundled 2242 mounting kit.
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, SM BIOS 3.0, ACPI
6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ
Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modied log, F12
PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability
DMI 3.0, WOL by PME, PXE
Support DVD
contents
Drivers
ASUS Utilities
ASUS EZ Update
Anti-virus software (OEM version)
Operating
system support
Windows
®
10 64-bit
Windows
®
8.1 64-bit*
Windows
®
7* 32-bit/64-bit*
* Windows
®
8.1 64-bit and Windows
®
7 32/64-bit are only supported when using
6th Generation Intel
®
Processors.
Form factor
Mini ITX Form Factor, 6.7” x 6.7” (17cm x 17cm)
Specications are subject to change without notice. Please refer to the ASUS website for
the latest specications.
