(continued on the next page)
SABERTOOTH 990FX R3.0 specifications summary
USB
2 x ASMedia
®
USB 3.1 controllers - supports ASUS USB 3.1 Boost and
3A power output
- 1 x USB 3.1/3.0/2.0 port @back panel (Type C)
- 3 x USB 3.1/3.0/2.0 ports @back panel (teal blue, Type A)
ASMedia
®
USB 3.0 Hub - supports ASUS USB 3.1 Boost
- 8 x USB 3.0/2.0 ports (4 ports at mid-board, 4 ports at back panel)
AMD
®
SB950 Chipset
- 8 x USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at back panel)
Exclusive TUF
Features
“Ultimate COOL!” Thermal Solution
- TUF Thermal Radar 2
“TUF ENGINE!” Digital Power Design
- 8+2 Digital Phase Power Design
- ASUS DIGI+ Power Control Utility
- TUF Components (Alloy choke, Cap. & MOSFET; certied by military-
standard)
“Safe & Stable!” Guardian Angel
- TUF ESD Guards 2
- TUF LANGuard
- MemOK!
Other Special
Features
- USB 3.1 Boost featuring speedy USB 3.1 transmission
- ASUS SafeSlot
- Ai Suite 3
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- USB BIOS Flashback with USB BIOS Flashback Wizard for EZ BIOS
download scheduling
- DRCT header
- ASUS Q-Connector
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS O.C. Prole
- ASUS EZ Flash 2
- Multi-language BIOS
