SABERTOOTH 990FX R3.0 specifications summary
Back Panel I/O
Ports
1 x Optical S/PDIF Output port
1 x USB 3.1/3.0/2.0 port (Type C)
3 x USB 3.1/3.0/2.0 port (teal blue, Type A)
1 x LAN (RJ45) port
4 x USB 3.0/2.0 ports (blue)
4 x USB 2.0/1.1 ports(one port can be used as USB BIOS Flashback port)
8-channel Audio I/O(5 x Audio jacks)
Internal I/O
Connectors
2 x USB 3.0/2.0 connectors support additional 4 USB 3.0/2.0 ports (19-pin)
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
5 x SATA 6Gb/s connectors
1 x CPU Fan connector (4-pin)
1 x CPU Opt fan connector (4-pin)
1 x Water Pump header (4-pin)
3 x Chassis Fan connectors (4-pin)
1 x TPM header
Front panel audio connector
1 x COM port
1 x S/PDIF Out header
24-pin EATX Power connector
8-pin EATX 12V Power connector
System Panel (Q-Connector)
1 x DRCT header
1 x Power on button
1 x MemOK! button
1 x USB BIOS Flashback button
1 x Clear CMOS header
BIOS
64 Mb Flash ROM, UEFI BIOS, PnP, SLP2.1, DMI2.0, WfM2.0, SM BIOS
2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree
BIOS 3, My Favorites, Quick Note, Last Modied log, F12 PrintScreen, F3
Shortcut functions, and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Support DVD
Drivers
Anti-virus software (OEM version)
ASUS Update
ASUS Utilities
Form Factor
ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm)
Specications are subject to change without notice.
