xii
Package contents
Check your motherboard package for the following items.
User Manual
ASUS SABERTOOTH 990FX R3.0
motherboard
User manual Support DVD
4 x Serial ATA 6.0 Gb/s cables 1 x ASUS SLI™ bridge connector 1 x TUF Certification card
Five-year warranty
1 x ASUS Q-Shield 1 x Q-Connector
1 x TUF Five-year warranty manual
(by region)
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specications may
vary with different models.
