ELLIPTICAL CROSS TRAINER ~ PARTS LIST
PART
No.
DESCRIPTION Q'TY
PART
No.
DESCRIPTION Q'TY
PART
No.
DESCRIPTION Q'TY
001 MAIN FRAME
1
119 DRIVE PULLEY 1 315 BOLT 8
002 STABILIZER - FRONT
1
120 WHEEL CAP - RIGHT 1 316 BOLT 6
003 STABILIZER - REAR
1
121 WHEEL CAP - LEFT 1 317 BOLT 4
004 UPRIGHT TUBE
1
122 HEIGHT ADJUSTMENT CAP 2 318 BOLT 4
005 DUAL ACTION ARM - LEFT
1
123 HEIGHT ADJUSTMENT FOOT 2 400 WASHER 12
006 DUAL ACTION ARM - RIGHT
1
124 POLY "V" DRIVE BELT 1 401 WASHER 4
007 DUAL ACTION HANDLE - LEFT
1
125 TIMING BELT 2 402 WASHER 2
008 DUAL ACTION HANDLE - RIGHT
1
126 TOP PIVOT COVER CAP 2 403 WASHER 4
009 MAIN COVER BRACKET 127 FOAM GRIP 2 404 WASHER 1
010 DRIVE PULLEY SHAFT
1
128 DUAL ACTION KNOB 2 405 WASHER 2
011 FOOT PEDAL TUBE - LEFT
1
129 ANGLE ADJUSTMENT SLIDER 2 406 WASHER 2
012 FOOT PEDAL TUBE - RIGHT
1
130 PANCAKE ALUMINUM 1 407 WASHER 4
013 TRIANGULAR ALI TUBE
1
131 PANCAKE SLEEVE 2 408 WASHER 2
014 ANGLE ADJUSTMENT TUBE 2 132 FRONT PIVOT SLIDER 2 500 SCREW 1
015 FRONT PIVOT SHAFT 2 133 ANGLE ADJUSTMENT SAFETY BUTTON 2 501 SCREW 18
016 ANGLE ADJUSTMENT CLAMP 2 134 WATER BOTTLE 1 502 SCREW 4
017 STATIONARY HANDLEBAR 1 135 HANDLE BAR COVER - REAR 1 503 SCREW 10
018 LONG CRANK 2 136 HANDLE BAR COVER - FRONT 1 504 SCREW 4
019 SHORT CRANK 2 137 FOAM GRIP 1 505 SCREW 2
020 TENSION WHEEL SHAFT 2 138 TOP PIVOT COVER OUTER 2 506 SCREW 6
021 SMALL PULLEY 2 139 BEARING BUSHING 6003 6 507 SCREW 2
022 SMALL PULLEY SHAFT 2 140 BEARING BUSHING 6904 2 600 C CLIP 2
023 LARGE PULLEY
2 141
UPRIGHT TUBE SPACER
2 700
MOTOR TENSION CABLE
1
024 FLYWHEEL WITH MAGNETS 1 142 TOP PIVOT COVER INNER 2 701 MOTOR with CABLE
1
025 SMALL PULLEY COVER 2 200 NUT 4 702 SENSOR with CABLE
1
100 PANCAKE SLIDER 1 201 NUT 4 703 COMPUTER CABLE
1
101 PANCAKE SLIDER WHEEL 1 202 NUT 2 704 HAND PULSE CABLE
1
102 PANCAKE CABLE GUIDE 3 203 NUT 2 705 HAND PULSE SENSOR
103 DISK COVER 2 204 NUT 2 706 PANCAKE SLIDER CABLE
1
104 HUB COVER 2 300 BOLT 2 707 PANCAKE FLYWHEEL SHAFT
1
105 TOP COVER
1
301 BOLT 2 708 PANCAKE SPRING
1
106 MAIN COVER - LEFT
1
302 BOLT 8 709 SENSOR MAGNET
1
107 MAIN COVER - RIGHT
1
303 BOLT 4 710 AC SOCKET with CABLE - LONG
1
108 FRONT PIVOT COVER - LEFT OUTER
1
304 BOLT 4 711 AC SOCKET with CABLE - SHORT
1
109 FRONT PIVOT COVER - LEFT INNER
1
305 BOLT 4 712 AC ADAPTOR
1
110 FRONT PIVOT COVER PLUG 306 BOLT 8 713 COMPUTER
1
111 HAT COVER
1
307 BOLT 2 714 AC CABLE
1
112 FRONT PIVOT COVER - RIGHT INNER
1
308 BOLT 4 715 HAND PULSE CABLE 2
113 FRONT PIVOT COVER - RIGHT OUTER
1
309 BOLT 2 800 BEARING IJK 6001ZZ 3
114 O - RING 2 310 BOLT 2 801 BEARING 6004ZZ SPEED 2
115 FOOT PEDAL 2 311 BOLT 2 802 BEARING 6003ZZ MOTO 6
116 FOOT PEDAL PLUG 4 312 BOLT 2 803 BEARING 6904ZZ SPEED 6
117 REAR PIVOT COVER 2 313 BOLT 18 804 BEARING 2203ZZ EZO JAPAN 2
118 PIVOT PLUG 4 314 BOLT 8 805 BEARING 6003ZZ EZO JAPAN 4
