Infinity Q21 [7/16] Elliptical cross trainer parts list

Infinity Q21 [7/16] Elliptical cross trainer parts list
ELLIPTICAL CROSS TRAINER ~ PARTS LIST
PART
No.
DESCRIPTION
Q'TY
PART
No.
DESCRIPTION
Q'TY
PART
No.
DESCRIPTION
Q'TY
001
MAIN FRAME
1
119
DRIVE PULLEY
1
315
BOLT
8
002
STABILIZER - FRONT
1
120
WHEEL CAP - RIGHT
1
316
BOLT
6
003
STABILIZER - REAR
1
121
WHEEL CAP - LEFT
1
317
BOLT
4
004
UPRIGHT TUBE
1
122
HEIGHT ADJUSTMENT CAP
2
318
BOLT
4
005
DUAL ACTION ARM-LEFT
1
123
HEIGHT ADJUSTMENT FOOT
2
400
WASHER
12
006
DUAL ACTION ARM-RIGHT
1
124
POLY "V" DRIVE BELT
1
401
WASHER
4
007
DUAL ACTION HANDLE - LEFT
1
125
TIMING BELT
2
402
WASHER
2
008
DUAL ACTION HANDLE - RIGHT
1
126
TOP PIVOT COVER CAP
2
403
WASHER
4
009
MAIN COVER BRACKET
127
FOAM GRIP
2
404
WASHER
1
010
DRIVE PULLEY SHAFT
1
128
DUAL ACTION KNOB
2
405
WASHER
2
011
FOOT PEDAL TUBE - LEFT
1
129
ANGLE ADJUSTMENT SLIDER
2
406
WASHER
2
012
FOOT PEDAL TUBE - RIGHT
1
130
PANCAKE ALUMINUM
1
407
WASHER
4
013
TRIANGULAR ALI TUBE
1
131
PANCAKE SLEEVE
2
408
WASHER
2
014
ANGLE ADJUSTMENT TUBE
2
132
FRONT PIVOT SLIDER
2
500
SCREW
1
015
FRONT PIVOT SHAFT
2
133
ANGLE ADJUSTMENT SAFETY BUTTON 2
501
SCREW
18
016
ANGLE ADJUSTMENT CLAMP
2
134
WATER BOTTLE
1
502
SCREW
4
017
STATIONARY HANDLEBAR
1
135
HANDLE BAR COVER - REAR
1
503
SCREW
10
018
LONG CRANK
2
136
HANDLE BAR COVER - FRONT
1
504
SCREW
4
019
SHORT CRANK
2
137
FOAM GRIP
1
505
SCREW
2
020
TENSION WHEEL SHAFT
2
138
TOP PIVOT COVER OUTER
2
506
SCREW
6
021
SMALL PULLEY
2
139
BEARING BUSHING 6003
6
507
SCREW
2
022
SMALL PULLEY SHAFT
2
140
BEARING BUSHING 6904
2
600
С CLIP
2
023
LARGE PULLEY
2
141
UPRIGHT TUBE SPACER
2
700
MOTOR TENSION CABLE
1
024
FLYWHEEL WITH MAGNETS
1
142
TOP PIVOT COVER INNER
2
701
MOTOR with CABLE
1
025
SMALL PULLEY COVER
2
200
NUT 4
702
SENSOR with CABLE
1
100
PANCAKE SLIDER
1
201
NUT 4
703
COMPUTER CABLE
1
101
PANCAKE SLIDER WHEEL
1
202
NUT 2
704
HAND PULSE CABLE
1
102
PANCAKE CABLE GUIDE
3
203
NUT 2
705
HAND PULSE SENSOR
103
DISK COVER
2
204
NUT 2
706
PANCAKE SLIDER CABLE
1
104
HUB COVER
2
300
BOLT
2
707
PANCAKE FLYWHEEL SHAFT
1
105
TOP COVER
1
301
BOLT
2
708
PANCAKE SPRING
1
106
MAIN COVER - LEFT
1
302
BOLT
8
709
SENSOR MAGNET
1
107
MAIN COVER - RIGHT
1
303
BOLT
4
710
AC SOCKET with CABLE - LONG
1
108
FRONT PIVOT COVER - LEFT OUTER
1
304
BOLT
4
711
AC SOCKET with CABLE - SHORT
1
109
FRONT PIVOT COVER - LEFT INNER
1
305
BOLT
4
712
AC ADAPTOR
1
110
FRONT PIVOT COVER PLUG
306
BOLT
8
713
COMPUTER
1
111
HAT COVER
1
307
BOLT
2
714
AC CABLE
1
112
FRONT PIVOT COVER - RIGHT INNER
1
308
BOLT
4
715
HAND PULSE CABLE
2
113
FRONT PIVOT COVER - RIGHT OUTER
1
309
BOLT
2
800
BEARING IJK6001ZZ
3
114
О - RING
2
310
BOLT
2
801
BEARING 6004ZZ SPEED
2
115
FOOT PEDAL
2
311
BOLT
2
802
BEARING 6003ZZ MOTO
6
116
FOOT PEDAL PLUG
4
312
BOLT
2
803
BEARING 6904ZZ SPEED
6
117
REAR PIVOT COVER
2
313
BOLT
18
804
BEARING 2203ZZ EZO JAPAN
2
118
PIVOT PLUG
4
314
BOLT
8
805
BEARING 6003ZZ EZO JAPAN
4
