ASRock FATAL1TY X299 PROFESSIONAL GAMING I9 [17/109] English
![ASRock FATAL1TY X299 PROFESSIONAL GAMING I9 [17/109] English](/views2/1252743/page17/bg11.png)
English
9
Fatal1ty X299 Professional Gaming i9 Series
No. Description
1 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
3 ATX 12V Power Connector (ATX12V1)
4 CPU Fan / Waterpump Fan Connector (CPU_OPT/W_PUMP)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2)
6 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1)
7 CPU Fan Connector (CPU_FAN1)
8 RGB LED Header (RGB_LED2)
9 ATX Power Connector (ATXPWR1)
10 Virtual RAID On CPU Header (VROC1)
11 USB 3.0 Header (USB3_7_8)
12 Front Panel Type C USB 3.1 Header (USB31_TC_2)
13 USB 3.0 Header (USB3_5_6)
14 SATA3 Connectors (SATA3_0_1)
15 SATA3 Connectors (SATA3_2_3)
16 SATA3 Connectors (SATA3_4_5)
17 SATA3 Connectors (SATA3_6_7)
18 SATA3 Connectors (SATA3_A1_A2)
19 Power LED and Speaker Header (SPK_PLED1)
20 Chassis Fan Connector (CHA_FAN1)
21 System Panel Header (PANEL1)
22 Reset Switch (RSTBTN1)
23 Power Switch (PWRBTN1)
24 Chassis Fan / Waterpump Fan Connector (CHA_FAN3/W_PUMP)
25 USB 2.0 Header (USB3_4)
26 USB 2.0 Header (USB1_2)
27 TPM Header (TPMS1)
28 underbolt AIC Header (TB1)
29 RGB LED Header (RGB_LED1)
30 Clear CMOS Jumper (CLRMOS1)
31 Front Panel Audio Header (HD_AUDIO1)
32 Chassis Fan Connector (CHA_FAN2)
