English
45
Fatal1ty X299 Professional Gaming i9 Series
For the latest updates of M.2_SSD (NFGG) module support list, please visit our website for
details: http://www.asrock.com
WD SATA3 WDS100T1B0B-00AS40
WD SATA3 WDS240G1G0B-00RC30
WD PCIe3 x4 WDS256G1X0C-00ENX0 (NVME)
WD PCIe3 x4 WDS512G1X0C-00ENX0 (NVME)
