ASRock H270M-ITX/ac [14/81] English
![ASRock H270M-ITX/ac [14/81] English](/views2/1253669/page14/bge.png)
8 9
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Chassis Fan / Waterpump Fan Connector (CHA_FAN1/W_PUMP)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5 ATX Power Connector (ATXPWR1)
6 USB 3.0 Header (USB_6_7)
7 SATA3 Connector (SATA3_1)
8 SATA3 Connector (SATA3_0)
9 SATA3 Connector (SATA3_3)
10 SATA3 Connector (SATA3_2)
11 System Panel Header (PANEL1)
12 USB 2.0 Header (USB_3_4)
13 Clear CMOS Jumper (CLRMOS1)
14 Chassis Intrusion Header (CI1)
15 SATA3 Connector (SATA3_4)
16 SATA3 Connector (SATA3_5)
17 Chassis Speaker Header (SPEAKER1)
18 TPM Header (TPMS1)
19 Front Panel Audio Header (HD_AUDIO1)
