Overview of Machine
-14-
Available Options
The following options are available for your
machine:
Second tray unit (tray 2)
Reference
For details on how to install the options, refer to "Installing
Options" P. 22.
Installation Requirements
Installation Environment
Your machine must be installed in the following
environment:
Note
Be careful of condensation. It may cause a malfunction.
If installing your machine where the humidity of the
surrounding air is less than 30% RH, use a humidifier or
antistatic mat.
Temperature: 10°C~32°C
Humidity: 20%~80% RH(relative
humidity)
Maximum wet
bulb temperature: 25°C
Do not install near high temperature or the fire.
Please do not install in a place from which
chemical reactions take place (laboratory etc.).
Do not install near inflammable solutions, such as
alcohol and thinner.
Do not install in places easily accessible to small
child.
Do not install in an unstable place (the shaky
stand, leaning place, etc.).
Do not install in a place exposed to high humidity,
dust or direct sunlight.
Do not install in an environment exposed to briny
air or corrosive gas.
Do not install in a place with much vibration.
Do not install in a place where the ventilation hole
of the machine is blocked.
Do not place directly on a rug or carpet with long
strands.
Do not install in a closed room with poor
ventilation and circulation.
If you use the machine in a small room for a long
time, please make sure that you ventilate the
room.
Install away from strong magnetic fields and
sources of noise.
Install away from monitors or TVs.
When moving the machine, hold it on both sides,
and move it by slightly letting the back of it fall.
WARNING
CAUTION
