Specifications (MB441/MB451/MB451w)
-188-
Print From USB Memory Specifications
Network Specifications
Output method Face down
Paper output capacity Face down
150 sheets (less than 80 g/m
2
)
Print guaranteed area 6.35 mm or more from the paper edge (not applicable to special media such as
envelopes)
Print precision Print beginning:± 2 mm, paper skew: ± 1 mm/100 mm, image expansion: ± 1 mm/100
mm (80 g/m
2
)
Warm-up time From power on
Less than 60 seconds
From power save mode
Less than 25 seconds
Usage Environment
Conditions
When in operation
10~32°C / Relative Humidity of 20~80% (maximum wet bulb temperature of 25°C,
maximum dry bulb temperature of 2°C)
When not in operation
0~43°C / Relative Humidity of 10~90% (maximum wet bulb temperature of 26.8°C,
maximum dry bulb temperature of 2°C)
Conditions for the
guarantee of print
quality
Temperature 10°C, humidity 30 to 78% RH/ temperature 32°C, humidity 30 to 54% RH/
humidity 30% RH, temperature 10 to 32°C/ humidity 80% RH, temperature 18 to 27°C
Consumables,
Maintenance Unit
Toner cartridges, image drum
MB441 MB451 MB451w
Interface USB 2.0 (High Speed) Host IF
Storage device USB memory (Up to 32 GB)
Not all USB memory products are guaranteed to work.
Supported file system FAT12, FAT (FAT16), FAT32
File format TIFF (TIFF 6.0 Baseline),
PRN (PCL)
PDF (v1.7, Does not support encrypted PDF), JPEG, TIFF
(TIFF 6.0 Baseline), PRN (PS/PCL)
MB441 MB451 MB451w
Interface Ethernet 10BASE-T/100BASE-TX Ethernet 10BASE-T/
100BASE-TX, IEEE820.11 b/
g/n Wireless LAN
Protocol TCP/IPv4, TCP/IPv6, NetBEUI, NetBIOS over TCP,
EtherTalk, NetWare, LPR, Port9100, IPP, FTP, HTTP,
TELNET, SMTP, POP3, SNMPv1/v3, DHCP, BOOTP, DNS,
DDNS, UPnP, WINS, SLP, Bonjour (Rendezvous), SNTP,
LLTD, Web Services Discovery (WSD), SSL/TLS, IPSec,
CIFS, SMB (Version 1.0), LDAPv3, Kerberos
TCP/IPv4, TCP/IPv6, NetBEUI,
NetBIOS over TCP, EtherTalk,
NetWare, LPR, Port9100, IPP,
FTP, HTTP, TELNET, SMTP,
POP3, SNMPv1/v3, DHCP,
BOOTP, DNS, DDNS, UPnP,
WINS, SLP, Bonjour
(Rendezvous), SNTP, LLTD,
Web Services Discovery
(WSD), SSL/TLS, IPSec, CIFS,
SMB (Version 1.0), LDAPv3,
Kerberos, IEEE820.11 b/g/n,
Infrastructure Mode, WEP,
WPA(TKIP/AES), WPS-PCB/
WPS-PIN, Open system
authentication, IEEE802.1x
authentication
