Error Messages
-148-
Checking the Machine's Status From the <STATUS> Key
From the <STATUS> key on the operator panel, you can check the status of your machine.
Checking the Trouble Status
The <
STATUS
> key blinks or lights up when any trouble is occurring in your machine. Press it to check the
trouble status.
1 Press the <STATUS> key on the
operator panel to open the status menu.
2 Be sure that [System Status] is
selected and then press .
3 Press the to select the item you want
to check and then press .
Checking the Device and Job Status
You can check the device status, such as the residual life of the consumable items, and job lists from the
<
STATUS
> key.
1 Press the <STATUS> key on the
operator panel to open the status menu.
2 Press the to select [Device
Information] and then press .
3 Press the to select the item you want
to check and then press .
OK
OK
OK
OK
