Specifications (MB461/MB471/MB471w/MB491/ES4161 MFP/ES4191 MFP)
-178-
Copier Specifications
Fax Specifications
Interface USB 2.0 (Hi-Speed), Ethernet 10BASE-T/
100BASE-TX
USB 2.0 (Hi-Speed),
Ethernet 10BASE-T/
100BASE-TX,
IEEE820.11 b/g/n
Wireless LAN
USB 2.0 (Hi-Speed),
Ethernet 10BASE-T/
100BASE-TX
Display Graphics panel 84.1(W) x 33.6(H) mm, 320 x 128 dots
Supported OS Windows 7, Windows Vista, Windows Server 2008 R2, Windows Server 2008, Windows
XP, Windows Server 2003
Mac OS X 10.4.0-10.7
Please refer to "Product Requirements" (P.46)
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
Document
size
ADF
A6 , B5 , A5 , A4 , letter , legal 13/13.5/14, executive
Document
glass
A6 , B5 , A5 , A4 , letter , executive
First copy
Time
Mono Less than 11
seconds (ADF, High
Speed)
Less than 11
seconds (ADF, High
Speed)
Less than 11
seconds (ADF, High
Speed)
Less than 10
seconds (ADF, High
Speed)
Copies Up to 99
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
Compatibility - ITU-T G3/Super G3
Compression method - MH, MR, MMR, JBIG
Modem speed - Up to 33.6 Kbps
Lines - PSTN, PBX Line
Line interface - RJ11 x 2 (Line/TEL)
Document
size
ADF - A4, letter, legal 13/13.5/14
Document
glass
- A4, letter
Transmission speed - Approx. 3 seconds/page (ITU-T, MMR, Normal)
Stored document
memory size
-4 MB
Storage document
capacity
- Up to 200 pages (ITU-T no.1, MMR, Normal)
Resolution - Normal
8 dots x 3.85 line/mm
Fine
8 dots x 7.7 line/mm
8 dots x 7.7 line/mm
Extra-Fine
8 dots x 15.4 line/mm
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
